Toggle Clamp with vertical lever - Fixed arm - Vertical base

Home / Catalog / Toggle clamps / Toggle Clamp with vertical lever - Vertical base / Toggle Clamp with vertical lever - Fixed arm - Vertical base
  • Toggle Clamp with vertical lever - Vertical base Toggle Clamp With Vertical Lever - Fixed Arm - Vertical Base 1
  • Toggle Clamp with vertical lever - Vertical base Toggle Clamp With Vertical Lever - Fixed Arm - Vertical Base 2
Description
Holding force: 2500KG max.
the handle swivels 125°.
the arm swivels 195°.
supplied as standard with neoprene tipped brooch
Download IGS file
REFERENCESMATERIALTHEORETICAL WEIGHT
SGH.212500-VMWhite zinc steel6500gr
* Articles made on request
