Description
Holding force: 550KG max.
the handle swivels 48°.
the arm swivels 100°.
supplied as standard with neoprene tipped brooch
REFERENCESMATERIALTHEORETICAL WEIGHT
SGH.210550-HMWhite zinc steel2540gr
* Articles made on request
