Toggle Clamp with vertical lever - Fixed arm - Horizontal base

Home / Catalog / Toggle clamps / Toggle Clamp with vertical lever - Horizontal base / Toggle Clamp with vertical lever - Fixed arm - Horizontal base
  • Toggle Clamp with vertical lever - Horizontal base Toggle Clamp With Vertical Lever - Fixed Arm - Horizontal Base 1
  • Toggle Clamp with vertical lever - Horizontal base Toggle Clamp With Vertical Lever - Fixed Arm - Horizontal Base 2
Description
Holding force: 340KG max.
the handle swivels 105°.
the arm swivels 58°.
supplied as standard with neoprene tipped brooch
REFERENCESMATERIALTHEORETICAL WEIGHT
SGH.210340-HMWhite zinc steel680gr
* Articles made on request
